1″ balancing valve with flow meter 10 bar, 110 °C, 10 to 40 L/min en soldes

1″ balancing valve with flow meter 10 bar, 110 °C, 10 to 40 L/min CALEFFI reference 132602.

Balancing valve with flow meter.
Direct reading of the flow rate.
Valve body and flow meter made of brass.
Ball valve for flow control.
Graduated scale flow meter with magnetic displacement indicator.

With insulating shell.
Pmax of exercise: 10 bar.
Temperature range: -10-110 °C.
Maximum percentage of glycol: 50 %.

The balancing valve is used to precisely regulate the flow to the elements of a heating or cooling system.

This series of balancing valves is specially designed to work in high temperature systems with high glycol content, typical conditions of solar systems.

The body is chrome plated.
