RAMON SOLER « New fly » wall-mounted bath shower mixer part no. 570502S.
Technical specifications
● CSTB certification with ECAU
● Ø35 mmceramiccartridge.
● C2 water-saving system through two-phase lever opening.
● Flow rate at 3 bar: 20 l/min bath outlet and 12 l/min shower outlet.
● Resistant to thermal and chemical shock for legionella protection.
● Operating pressure between 1-5 bar. Recommended at 3 bar.
● Withstands static pressures equal to or less than 10 bar and water hammer up to 25 bar.
● Noise level at 3 bar: less than 20 dB.
● Comfort benefits in terms of fidelity, sensitivity and comfort in temperature selection.
● Recommended hot water temperature 55ºC. Maximum operating temperature 65°C. Maximum 1h at 90°C.
● Chrome-plated surface: 15 microns thick nickel, 0.3 microns chrome.
● Termostop Block system for limiting maximum hot water temperature
| Weight (kg) : | 1.5 |
|---|---|
| Packaging: | 1 |
| Main materials : | Ceramics |
| Finishes : | Chrome |
| Warranty: | 2 years |
| Origin: | made in europe |
| EAN13 | 8428506035722 |
