90 LED 16W flat color spotlight + remote control

FLAT LED POOL LIGHT – COLOR LIGHT

Model: 502877
Type: 90 LED 3528 / 120°.
Color: 30R, 30V, 30B
Controller: On/Off and 433Mhz radio tel
Functions: 11 colors and 5 programs
Materials: support and optics in
polycarbonate (PC), ASA cover
Screwed into 1.5″ brush socket
Connection: 2 metal screw terminals
H07RNF cable 2m, 2×1.5mm2

Contents of the package :

– Flat Led Projector
– 1 white crown
– 2 thermo connectors
– 2 joints
– 1 cable 2m H07RNF 2×1,5mm2
– Installation kit for inground pool
– 5 nylon screws (PA)
– Remote control
– 1 CR2032 battery
– Installation and Operating Instructions

Electricalparameter:

– Max instantaneous power: 16W*.
– Stabilized power >1h : N/A
– Supply voltage: ~12V(AC) 50/60Hz or ⎓20V(DC)
– PF max : 0,7 if ~12V(AC)
– PF max: 1 if ⎓20V(DC)
– Minimum power supply ~12V(AC) [(Pi /PF)+20%] : 28VA
– Electrical class: III
– EEI: N/A

Otherparameters:

– Protection class: IP68*.
– Product lifetime : 15 000h
– Switching cycles: > 100,000
– Use: for immersion in water only

Use a connection cable with a minimum cross-section of 2 x 1mm² to be adapted according to the distance between the connection box of the projector and the transformer as well as the absorbed power.
